Product Details
＋
The IAMS Universal Signal Conditioners unmatched capability provides users the ultimate in flexibility. As a signal conditioner, the unit provides complete isolation and conversion capability to satisfy almost any application. The Universal Input accepts Process, DC Current, DC Voltage, Thermocouples, RTDs, Potentiometers, and Linear Resistance signals allowing the module to be connected to most sensors. The setpoint model allows dual setpoint control capability through dual Form A relays. The analog model provides a retransmitted analog signal. A third model provides both analog and dual setpoint control capability. The power supply is universal, accepting 21.6 to 253 VAC/ 19.2 to 300 VDC as its power source. Add the optional programming module and the unit is easily programmed through menu style programming. The module can
also be used to provide a display of the process variable when it is not being used for programming.
Specifications:
- Input Type: Universal
- Interface: PGMMOD00
- Number of Channels: 4 (Output)
- Output Type: Current
- Series: IAMS Series
- Supply Voltage: 21.6 to 253 VAC/19.2 to 300 VDC
- Termination: Screw
